Description
2610 Swiss Motor Replacement Rotary Tattoo Machine motor for Sunshine Tattoo Guns Dragonfly Tattoo Machine parts liner shader
Specifications:
Condition:New
Net Weight: 25g ±0.3g
Dia.:17mm. Length:23-25mm ±0.2mm
Shaft Length:5.6±0.03mm,Shaft Diameter: 1.5mm ±0.01mm
Rated voltage: 12V
Rotation direction: CW
No load speed: 11200 rpm
No load current: 0.025 Amps
Locked rotor torque: 17.640 mN. n
Locked rotor current: 1.700 Amps
Maximum efficiency point
Efficiency: 80.6%
Torque: 1.940 mN.m
Speed: 9968 rpm
Current: 0.209 amps
Power: 2.024 watts
maximum power point
Power: 5.277 watts
Torque: 8.820 mN.m
Speed: 5600 rpm
Current: 0.863 Amps
features
Torque constant: 10.376 mN_m/AMP
EMF constant: 10.376 mV/rad/sec
dynamic resistance:7.0588 Ohms
Motor regulation: 634.92 RPM / mN.m
Features:
1.The Motor efficiently stable and powerful
2.Fluent and powerful working but lower vibration.
3.Easy installed
5.Extraordinarily light, silent, and ergonomic, these Motor greatly surpass any competition
Packing include: One 2610 Swiss Motor
